Rail Joints

Introduction of Railway Joints

As the core equipment of modern rail transit, the reliability of the connection system of rail vehicles directly affects the safety and efficiency of train operation.

1. Load-bearing connection bracket system: As the mechanical center of the entire vehicle structure, the connection bracket is formed by high-strength alloy casting and strengthened through three-dimensional finite element topology optimization design. This component has the following technical characteristics:

• Multi-directional load-bearing system: It can simultaneously withstand longitudinal traction force (maximum load ≥ 500kN), vertical pressure (design load 800kN), and lateral shear force, with a dynamic load factor of 1.8.

2.Reinforced hanging rib plate assembly: As a key force transmission component for the connection between the car body and the bogie, the new hanging rib plate is manufactured using laser welding technology and incorporates several innovative designs:

• Variable cross-section bionic rib design: Based on biomechanical principles, the gradually changing cross-section structure effectively disperses stress concentration.
• Nano-coating protection: The surface is treated with HVOF sprayed tungsten carbide coating, increasing wear resistance.
• Modular quick-release structure: Equipped with a patented wedge locking device, maintenance time is reduced by 70%.

3. Dynamic adaptive movable crossbeam assembly: As the movement hub of the connection system, this component has achieved three technological innovation breakthroughs:

• With a spherical bearing and cross-slot composite structure, it automatically compensates for ±5° deflection angles.
• Integrated with a micro-quantitative oil injection device, it automatically replenishes 12ml of grease every 100,000 kilometers of operation.
• With 7-series aluminum alloy forging technology, it reduces weight by 35% while maintaining a tensile strength of 900MPa.

Advantages of Railway Joints

Engineering practice shows that the new generation of connection systems, by optimizing the coordination of components, reduces the longitudinal impact force of the entire vehicle by 28% and extends the fatigue life of key connection points to 1.8 million kilometers. Particularly in terms of curve passing performance, the lateral force between the wheel and rail is reduced by 15% compared to traditional structures, fully demonstrating the progress of modern rail vehicle connection technology.

Company Profile

Luoyang Fenyo Heavy Industries Co., Ltd. was founded in 1998, covers an area of 72,600㎡, with more than 300 employees, 32 technicians, including 5 senior engineers, 11 assistant engineers, and 16 technicians. It has been rated as Luoyang Engineering Technology Center, Luoyang Technology R&D Center, and National High-tech Enterprise for many times.
Our production capacity is 30,000 tons per year. Currently, we mainly produce cast steel, cast iron (gray iron, ductile iron, etc.), processing of finished product and component assembly.the products have been exported to Russia, the United States, Germany, Argentina, Japan, France, South Africa,Italy and other countries.

Package

Polybag+Carton box+Wooden case/Pallet, according to customer's request

FAQS

Q1: Are you a manufacturer or trading company?
A:Yes,our company was founded in 1998, with nearly 30 years in casting industry, a total area of 72,600㎡, with a factory building area of 51,000㎡.
Q2. What are your main products?
A: We primarily focus on steel casting, iron casting, finished product machining, and component assembly production.
Q3: How precision can you produce casting parts?
A: We have the capability of producing casting parts with different casting processes. The production is strictly comply with ISO 9001, ISO 14001 and ISO45001,EN15085, IRIS.
Q4. Can you produce according to the samples?
 Yes, we can produce by your samples or technical drawings. We can build drawings for you after we get your samples too.
Q5: How do you do Quality Control before delivery?
A: Quality inspection is a very important factor to guarantee the quality of steel casting parts. We follow 3 times of inspection during the whole production process. And we will provide material testing report, dimensional testing report, and mechanical properties testing report to our clients before delivery.
