Railway Axle Box

Introduction Of Railway Axle Box

The axle box focuses on the stability of the terminal of power output. Its unique hydraulic damping system can absorb 80% of the wheel-rail impact vibration. The sealing structure adopts a multi-layer labyrinth design combined with magnetic fluid sealing technology, which increases the efficiency of isolating external contaminants to 99.97%. The temperature adaptive compensation mechanism can automatically adjust the axial clearance to the 0.05mm level, ensuring that the bearing system is always in the best working condition.

The axle box adopts a composite casting process of compacted graphite iron (CGI450) and aluminum alloy. The wall thickness of the box body has been designed through topology optimization, achieving a 30% weight reduction while ensuring structural strength. The copper-based graphite self-lubricating bushings embedded inside can maintain a stable coefficient of friction under operating conditions ranging from -40
℃ to 150℃.

Specifications of Railway Axle Box

Material	uctile iron (EN-GJS-500)/Cast steel (ZG270-500)
Bearing Type	Tapered roller bearings/cylindrical roller bearings
Installation Method	Bolt fastening/interference fit
Seal Design	Double lip contact seal + Magnetic encoder (dirt and moisture proof)
anti-corrosion treatment	Thermal spraying zinc-aluminum alloy (≥200μm) + epoxy coating
Transmission Ratio Range	3:1 - 10:1

Properties and Advantages of Railway Axle Box

(1)Class of protection
IP68 (mud, seawater intrusion prevention)
(2)Noise level≤75 dB (measured at 1 meter)
(3)Operating temperature:-40℃ ~ +80℃ (high temperature type up to +150℃)
(4)Vibration resistance class:EN 61373 (10-2000 Hz, 5-15 g)
(5)Dustproof and waterproof class: IP67/IP69K (High pressure flushing environment)

Applications for Railway Axle Box

Used for freight locomotive axle support, adapt to high dust, high humidity environment.
Applicable axle type: [Solid axle/hollow axle, axle diameter range (e.g. : φ120-φ200mm)

Company Profile

Luoyang Fenyo Heavy Industries Co., Ltd. was founded in 1998, covers an area of 72,600㎡, with more than 300 employees, 32 technicians, including 5 senior engineers, 11 assistant engineers, and 16 technicians. It has been rated as Luoyang Engineering Technology Center, Luoyang Technology R&D Center, and National High-tech Enterprise for many times.

Our production capacity is 30,000 tons per year. Currently, we mainly produce cast steel, cast iron (gray iron, ductile iron, etc.), processing of finished product and component assembly. The company mainly produces parts and railcar gearbox component assemblies for high-speed rail, railcars, locomotives, passenger cars, subways, mines, coal machines, petroleum machinery, wind power, water conservancy, ceramics, engineering machinery and other equipment. At the same time, the products have been exported to Russia, the United States, Germany, Argentina, Japan, France, South Africa, Italy and other countries.

Package of Railway Axle Box
Rust proof oil + vacuum seal + Wooden box (in accordance with export standards)
