Railway Axle Box for The Stability of The Terminal of Power Output

Introduction Of The Railway Axle Box

The axle box focuses on the stability of the terminal of power output. Its unique hydraulic damping system can absorb 80% of the wheel-rail impact vibration. The sealing structure adopts a multi-layer labyrinth design combined with magnetic fluid sealing technology, which increases the efficiency of isolating external contaminants to 99.97%. The temperature adaptive compensation mechanism can automatically adjust the axial clearance to the 0.05mm level, ensuring that the bearing system is always in the best working condition.

The axle box adopts a composite casting process of compacted graphite iron (CGI450) and aluminum alloy. The wall thickness of the box body has been designed through topology optimization, achieving a 30% weight reduction while ensuring structural strength. The copper-based graphite self-lubricating bushings embedded inside can maintain a stable coefficient of friction under operating conditions ranging from -40
℃ to 150℃

Specifications of Railway Axle Box

Material	High strength cast iron (GGG40)/Cast steel (EN-GJS-400)/Aluminum alloy
Gear Type	Helical gear/planetary gear/hypoid gear
Heat Treatment Process	Carburizing/nitriding treatment (tooth surface hardness ≥58 HRC)
Seal Design	Multistage labyrinth seal + fluoro rubber oil seal (IP67 protection)
Rated Input Torque	5000-20000 Nm (depending on model)
Transmission Ratio Range	3:1 – 10:1

Advantages Of Railway Axle Box

(1)Transmission efficiency 97% or higher

(2)Maximum input speed 3000-5000 rpm

(3)Noise level≤75 dB (measured at 1 meter)
(4)Operating temperature:-40℃ ~ +120℃ (high temperature type up to +150℃)
(5)Vibration resistance class:EN 61373 (10-2000 Hz, 5-15 g)
(6)Dustproof and waterproof class:IP67/IP69K (High pressure flushing environment)
