Railway Gearbox

Introduction Of Railway Gearbox

In the complex mechanical system of railway vehicles, the power transmission device of the bogie is like the skeletal and joint system of the human body. The gearbox, axle box, and axle housing not only undertake the core mission of power transmission but also play a crucial role in vehicle safety operation and energy consumption control.

Gearbox: The Core Hub of Power Transmission
As the "power converter" connecting the traction motor and the wheel set, modern railway vehicle gearboxes have evolved into highly integrated precision transmission systems. They feature a split-cast box structure with a three-stage reduction gear set, which can convert the high-speed output of the motor (typically 1500-4000 rpm) into a torque output suitable for wheel-rail contact (approximately 20-50 kN·m). The innovative variable cross-section gear set design, combined with tooth profile modification technology, boosts transmission efficiency to over 98.5% while reducing noise by 6-8 dB(A).

Specifications of Railway Gearbox

Material	High strength cast iron (GGG40)/Cast steel (EN-GJS-400)/Aluminum alloy
Gear Type	Helical gear/planetary gear/hypoid gear
Heat Treatment Process	Carburizing/nitriding treatment (tooth surface hardness ≥58 HRC)
Seal Design	Multistage labyrinth seal + fluoro rubber oil seal (IP67 protection)
Rated Input Torque	5000-20000 Nm (depending on model)
Transmission Ratio Range	3:1 - 10:1

Properties and Advantages of Railway Gearbox

(1)Transmission efficiency 97% or higher

(2)Maximum input speed 3000-5000 rpm

(3)Noise level≤75 dB (measured at 1 meter)
(4)Operating temperature:-40℃ ~ +120℃ (high temperature type up to +150℃)
(5)Vibration resistance class:EN 61373 (10-2000 Hz, 5-15 g)
(6)Dustproof and waterproof class: IP67/IP69K (High pressure flushing environment)

Applications for Railway Gearbox

Suitable for urban rail vehicle power transmission system, suitable for permanent magnet synchronous motor.
Applicable models:high-speed rail/subway/tram/freight locomotive(0-450 km/h)
