Internal combustion motor bolt wrench Internal combustion motor bolt wrench factory direct sales

Introduction of internal combustion motor bolt wrench

The internal combustion motor bolt wrench is a small track maintenance machine designed for tightening and loosening railway sleeper bolts and nuts. This equipment can significantly improve the efficiency and quality of the engineering and construction departments in tightening and loosening sleeper bolts and threaded spikes, greatly reducing the labor intensity of workers. It is an ideal tool for line laying and maintenance operations, with both economical and high-performance reliable characteristics.

This product is specially developed to meet the heavy workload of loading and unloading concrete sleeper bolts, and has the following advantages:

1. Simple and practical structural design
2. Strong and efficient impact force
3. Lightweight design for easy carrying
4. Flexible and convenient transportation operation
5. Clutch start-up is safe and reliable

Technical performance of internal combustion motor bolt wrench

160F diesel engine: 1.47kw 2600r/min
Sleeve torque: 360N·m	Impact head speed: 590r/min
Scope of application: Tightening and loosening of M24 sleeper bolts and threaded spikes
Operation efficiency: 1 piece/3S	Machine weight: 75kg
Dimensions: 1120×510×800(mm)

Safety Instructions for Using Internal Combustion Power Bolt Wrenches

Before performing equipment maintenance or servicing, be sure to confirm that the engine has been completely shut down. This can effectively avoid potential safety risks. When working in a working environment containing gasoline, special attention should be paid to fire and explosion prevention:

1. Only use non-flammable cleaning solvents
2. No smoking during the entire process
3. Strictly prohibit any form of open flames, electric sparks or high temperature sources

Core features of internal combustion motor bolt wrench

The internal combustion motor bolt wrench has seven core advantages: it is equipped with an imported internal combustion power engine to ensure strong output, the centrifugal clutch device achieves smooth transmission, and the convenient starting mechanism significantly improves operating efficiency; the equipment is equipped with a two-way impact assist system, which can realize the rapid disassembly and assembly of nuts, greatly shortening the operation cycle; the structural design follows the principle of lightweight, and the whole machine is streamlined and efficient, maintaining excellent operating performance while taking into account the convenience of operation; at the same time, its excellent ergonomic design ensures that the use process is light and safe, combined with the outstanding cost-effectiveness, it has become a rare ideal tool in the field of railway maintenance.
