Wind Power

Introduction of Wind Generator Housing

The casting-driven Generator housing is the core structural component in the industrial-driven Generator system. A precision casting process makes it and is mainly used to support the Wind Driven Generator impeller, guide the airflow direction and provide protection for the internal transmission components. Its design combines the principles of fluid mechanics and the concept of mechanical structure optimization. It plays a key role in the efficient ventilation and gas delivery systems in the fields of energy, electricity, metallurgy and chemical industry.

Specifications of Wind Power Generator Housing

Structure & Material
Shell Material	Internal Skeleton Material	Surface Treatment Technology	Structural Form
Aluminum alloy/High strength steel plate (e.g. S355)/Composite material	Hot-dip galvanized steel/stainless steel	Spray/anodizing/galvanizing (salt spray resistance ≥1000 hours)	Split modular design/integral welded type
Size & Weight
Gross Weight	Overall Dimensions (L×W×H)	Mounting Interface Size
800-2500 kg	3000×1500×2000 mm (customized size)	Flange standards (e.g. ISO 5210)
Environmental Suitability & Adaptation
Operating Temperature	Humidity Range	Salt Spray Resistance	Lightning Protection Design
(-)40° to 60°	≤95% RH (non-condensing)	≥2000 Hours (ASTM B117 standard)	Integrated ground terminal (resistance ≤4Ω)

Advantages of Wind Power Generate Housing

Protection Class (IP) IP67/IP68 (dustproof and waterproof)
Corrosion protection ISO 12944 C5-M (High corrosive environment)
Wind pressure resistance ≥ 1.5kPa (corresponding to Category 12 typhoon)
Seismic rating in accordance with IEC 61400-1 (magnitude 8 seismic intensity)
Cooling design Built-in cooling fan/ventilation shutter (cooling area ≥2㎡)
Noise reduction ≤65 dB (1 meter away measurement)

Company Profile

Our company was founded in 1998, covers an area of 72,600㎡, with more than 300 employees, 32 technicians, including 5 senior engineers, 11 assistant engineers, and 16 technicians. It has been rated as Luoyang Engineering Technology Center, Luoyang Technology R&D Center, and National High-tech Enterprise for many times.
Our production capacity is 30,000 tons per year. Currently, we mainly produce cast steel, cast iron (gray iron, ductile iron, etc.), processing of finished product and component assembly.the products have been exported to Russia, the United States, Germany, Argentina, Japan, France, South Africa,Italy and other countries.

Package of Wind Power Generate Housing

Polybag+Carton box+Wooden case/Pallet, according to customer's request

FAQS

Q1: Are you a manufacturer or trading company?
A:Yes,our company was founded in 1998, with nearly 30 years in casting industry, a total area of 72,600㎡, with a factory building area of 51,000㎡.
Q2. What are your main products?
A: We primarily focus on steel casting, iron casting, finished product machining, and component assembly production.
Q3: How precision can you produce casting parts?
A: We have the capability of producing casting parts with different casting processes. The production is strictly comply with ISO 9001, ISO 14001 and ISO45001,EN15085, IRIS.
Q4. Can you produce according to the samples?
 Yes, we can produce by your samples or technical drawings. We can build drawings for you after we get your samples too.
Q5: How do you do Quality Control before delivery?
A: Quality inspection is a very important factor to guarantee the quality of steel casting parts. We follow 3 times of inspection during the whole production process. And we will provide material testing report, dimensional testing report, and mechanical properties testing report to our clients before delivery.

It you are interested in any products,please feel free to contact us.
Contact:Cathy Xu
Mobile:008615515321683
